Blue-green deployment keeps two identical environments, often called blue and green. In Azure, these environments can be separate App Service deployment slots or distinct virtual machine scale sets. The live version (blue) continues to serve all traffic while the new version (green) is deployed and tested. Once the green environment passes health checks, a Azure Traffic Manager or Application Gateway routing rule switches incoming traffic from blue to green. The key relationship is that the switch is instantaneous: traffic moves from one environment to the other, so downtime is zero. If the green version fails, you simply route traffic back to blue, giving a fast rollback. This model works best when you need a clear, immediate cutover and have the resources to maintain two full environments.
Canary Deployment
Canary deployment sends a small percentage of users to the new version while the majority stays on the old one. In an Azure DevOps pipeline, you can configure a deployment slot or a traffic-weighting rule on Application Gateway to send, for example, 5% of requests to the canary and 95% to the stable version. The canary environment runs with the new code, and you monitor metrics such as error rates, latency, and user feedback. Only when the canary performs well do you increase its traffic share. The flow is gradual: the canary receives a small slice of traffic first, then expands as confidence grows. This strategy reduces risk because a failure affects only a few users, and you can stop the rollout quickly without affecting the majority.
Ring Deployment
Ring deployment is like canary but with multiple stages, or rings, each representing a larger audience. For example, the first ring might be internal testers, the second ring a small set of external users, and the third ring all users. In Azure, you can use Azure Traffic Manager to route traffic to different deployment slots based on geographic regions or user groups, or you can use feature flags to enable the new version for specific rings. Each ring acts as a gate: you validate stability and collect feedback in one ring before promoting the release to the next. The progression is controlled and tiered, ensuring that a problem is caught early in a small ring rather than affecting the entire user base. This approach is common for large-scale rollouts where risk tolerance varies by audience.
Progressive Exposure
Progressive exposure automatically shifts more traffic to the new version over time based on live performance metrics. In Azure, you can use Application Gateway with weighted backend pools to gradually increase the weight of the new version’s pool while decreasing the old version’s weight. The traffic shift is not manual; it is driven by a policy that watches metrics like CPU usage, request success rate, or response time. If the metrics fall below a threshold, the shift pauses or rolls back. The relationship between traffic and metrics is continuous: the deployment controller adjusts the traffic split dynamically, so the release is always exposed to the smallest risk that still allows validation. This strategy is best for teams that want an automated, hands-off rollout that reacts to real-world conditions.
Feature Flags
Feature flags let you turn features on or off in production without redeploying the application. In Azure, you can use Azure App Configuration to store feature flags and serve them to your application at runtime. The application code checks the flag before showing a new feature, so the flag controls behavior independently of the deployment pipeline. You can enable a feature for a small set of users (a canary with a flag) or for all users after validation. Feature flags also support A/B testing by toggling different flag values for different user segments. The key relationship is that deployment and feature release are decoupled: you can deploy code with new features disabled, then enable them gradually without a new deployment. This gives granular control and allows rapid rollback of a single feature by flipping the flag off.
A/B Testing
A/B testing runs two versions of the application side by side to compare user behavior and performance. In Azure, you can route traffic to two different deployment slots using Azure Traffic Manager or Application Gateway with weighted routing, or you can use feature flags to expose different feature sets to user groups. The results are collected from analytics, telemetry, and user feedback. Unlike a canary deployment, A/B testing is not about stability; it is about making a data-driven decision on which version leads to better outcomes. The decision to switch fully to version A or B comes after enough data is gathered. The relationship between the two versions is competitive: they run simultaneously, and the comparison guides the final choice. This strategy is ideal when you need to optimize user experience or business metrics before committing to a change.
